Bose Professional

Bose L1 Pro16 Portable Line Array

311468.00

Availability: Out Of Stock

  • 100% genuine, brand-warranted stock
  • Expert installation & room calibration
  • Free acoustic consultation before you buy
Description

The Bose L1 Pro16 Portable Line Array is a portable line array system from the Bose Professional portable range. AudioFusion Solutions is an authorised Bose Professional dealer: every unit is genuine, carries full manufacturer warranty, and can be delivered and installed anywhere in India.

Listed at ₹3,11,468 MRP (inclusive of taxes), per the Bose Professional portable price list effective 2026-05-01.

Full manufacturer specifications, a demonstration at our Gomti Nagar experience centre, or a system design around this product — talk to our team and we will put it together.

Technical specifications
Performance
Frequency range (-10 dB)
31 Hz – 18 kHz
Coverage, horizontal
180°
Coverage, vertical
0°/30°
Calculated maximum SPL @ 1 m
124 dB
Power handling, peak
1000 W
Transducers
High-frequency
16 × 2 in (51 mm) drivers
Low-frequency
1 × RaceTrack 10 × 18 in (254 × 457 mm) driver
Crossover
200 Hz
Amplification
Number of channels
2
Power class
Class D
Audio inputs
Input channels
3
Connectors
(1) XLR-1/4-in TRS combo, (1) 1/4-in TRS, (1) 1/8-in TRS, Bluetooth audio streaming
Phantom power
48 VDC, channels 1 & 2
Integrated DSP
DSP-enabled
Yes
Presets
ToneMatch presets
Processing
System EQ, reverb
Electrical
AC power input
100–240 VAC (±15%, 50/60 Hz)
AC power connector
IEC
Current draw, inrush
15.7 A at 120 VAC, 60 Hz / 28.4 A at 230 VAC, 50 Hz
Physical
Dimensions (H×W×D)
2011 mm × 355 mm × 456 mm (79.2 in × 14.0 in × 18.0 in)
Net weight
23.0 kg (50.6 lb)
Enclosure
Power stand: high-impact polypropylene / extension & array: high-impact ABS
Grille
Perforated steel, powder-coated
Cooling
Convection
General
App
Bose Music (Android, iOS)
Computer interface
USB Type-C
Safety
UL/IEC/EN62368-1

Specifications published by Bose Professional for 840920-5130. E&OE. Ask us if you need a detail that is not listed.
